    Dual Cooling Thermal Cycling Test Chamber , Environmental Test Chamber DCOSIC CRRC

    15℃/M Thermal Cycling Test Chamber , Environmental Test Chamber DCOSIC CRRC

    Detailed Product Description
    Temperature Range:-70°C~150°C Or Tailor-madeChange Rate:5-15°C/min Linear Speed Or Average Speed
    Electronic:AC220V·50HZ/380V·50HZMeet Test Standard:IEC, ASTM, MIL, ISO Etc
    Interior Material:SUS 304Refrigeration:Unit Cooling Mode / Dual Cooling Method (air-cooled)as Per Size Of Chamber And Specific Low Temperature
    Product Name:Environmental Test ChamberRefrigerant:Environmental Friendly R23/R404a

    15℃/m Rapid-Rate Thermal Cycling Test Chamber Designed for COSIC and CRRC


    Pruduct Description


    COSIC and CRRC​ are belonging to the Top 10 Military Enterpriser in China. Often our Standard model tset chamber can't meet their military standard , and we need to custom made in order to meet military industrial testing requirements. The test chamber can be remote controlled and pre-record test programs, so that customers can start test only click program numbers on the controller,on the computer or just on the cellphone.


    Application


    ESS Thermal Cycling Test Chamber is widely used in following industry and it can be used as an important reference for improving product quality.

    • Electronic parts
    • Home appliance
    • Auto parts
    • Aviation parts
    • Metal
    • Plastic,rubber

    Technical Sheet


    ModelMESS-250MESS-500MESS-1000MESS-1500Custom
    Interior Volume250L500L1000L800LAccept
    Interior Dimension(cm)70*70H*5080*90H*70100*100H*100100*150H*100
    Standard Load(Aluminum Ingots)5kg12kg25kg30kg
    Temp Change Rate(with load)5℃ ~20℃/m(Standard); 30/℃/m( Liquid Netrogen)
    Temp Range-70℃~+150℃-40℃~+150℃
    Temp Fluctuation±0.3℃~±0.5℃
    Temp & Humidity Deviation±1℃~±2℃±3%RH(>75%RH);±5%RH(≤75%RH) (optional)
    Standard configurations1 Window, 1 Cable port, 1 Lamp, 4 Casters, 1 Power cable, 2 Stainless steel shelves
    Standard Documentationsquality certification,test report ,user operaion manual for machine & controller
    Safety devicesElectric leakage, fan overheat ,anti-dry ,compressor overheat & overpressure,power supply undercurrent,overheat, overcurrent, phase sequence, over-temperature protection devices

    Why MENTEK?


    • 1) Highly flexible for customization: The biggest advantage with MTENK climatic chambers is that they are highly flexible for customization. Every test follows a set of procedures as per the defined test standards (ASTM, IEC, MIL, etc.) and sometimes a standard climatic chamber might not be sufficient to conduct a particular test. Our engineers understand this need of the industry well and offer the highest level of customisation like design modification or integration with other applications such as Climatic Chamber with alititude integration, Climatic Chamber with Vibration Integration(AGREE Chamber), etc.

    • 2) Professionalism: China Leading brand climatic chamber manufacturer with over 20 years focus on environmental test chambers Industry since 1999. MENTEK Testing Equipment Co.,Ltd is a leading climatic chamber manufacturer in China, specializing in manufacturing various environmental chambers with superior quality and customer service.We have professional factory management and development team. The yearly turnout are 1,500 units.We are customer-tailored solution expert in environmental chamber, provide excellent test chambers & make expert solutions for customers.We provide private custom service for each customer, and create their own brand environment test chambers.

    • 3) Fast Delivery: The products delivered to you within 7 days for our stock items from clearance of payment. It will take 25-to-35 working days for custom made products or equipments that are not available from stock.

    We Supply you


    • Climatic Chamber
    • Environmental Chamber
    • Temperature Chamber
    • Humidity Chamber
    • Walk-in Chamber
    • Thermal Shock Chamber
    • Thermal Cycling Chamber
    • Lab Oven
    • Vacuum Chamber
    • Vibration Shaker
    • Altitude Chamber
    • Salt Spray Tester
    • Tensile Test Machine
    • Custom-designed Test Chamber

    Looking for distributors worldwild.


    We have been looking for qualified overseas distributors or dealers to join our business together, and sincerely invite you to visit our company and factory in Dongguan, China. If you are interested in business for environmental chambers and have ability to install, repair test chambers with your professional technician support, please do not hesitate to contact us and join our sales team to establish friendly business relationship based on mutual benefits.
