Electric 220V or 380V 50Hz PID Temperature Controlled Hot Air Drying Oven

Hot air drying oven can provide a stable test space for pre-heating, drying, changes about physics and chemistry testing.It controls the temperature through the connection of digital display instrument and temperature sensor, and adopts the method of hot air circulating air supply. The shell is welded with high quality steel plate and the surface is treated by baking varnish. The inner chamber is made of mirror stainless steel #304.

Application

• Electronic parts
• Home appliance
• Auto parts
• Aviation parts

Features

• Anti-corrosion stainless steel 304 working chamber and high-quality steel plate exterior shell, the surface paint spraying.
• PID controlling Intelligent temperature controller .Digital temperature display with the functions of precise temperature control, timing range 0~9999min and over-temperature alarm.
• Hot air circulation with low-noisy air blower and optimal air duct to ensure even temperature distribution inside the chamber.
• The shelves can be equipped more according to customers’ requirements and the space between shelves can be adjusted.
• Double layer glass door,larger transparent viewing window to see the samples.
• Forced air convection.The heating power can be adjusted.
• Available in various technical specifications and capacities.We can customize oven as per customer requirement like size of chamber, temperature range,supply voltage,material of chamber,etc.

Technical Sheet

Model		MHG-72	MHG-125	MHG-270	MHG-600	MHG-1000
Interior Dimensions(cm)		45*40*40	50*50H*50	60*90H*50	100*100H*60	100*100H*100
Exterior Dimensions(cm)		65*115H*140	70*125H*160	800*165H*160	125*185H*175	125*180H*175
Power supply		AC1∮220V60/50Hz			AC3∮380V60/50Hz
Power(k.w.)		5	6	9	12	12
Temperature		RT﹢10℃~250℃
Performance	Controller precision	±0.5℃
	Temp uniformity	± 1.5 ° C below 100 ° C and 2.5 ° C above 100 ° C
	Resolution accuracy	0.1℃
	Heating time	60min
Material	Shell	High - strength cold - rolled steel plate double - sided powder baking
	Inner wall	SUS#201 Stainless steel 2B panel
	Insulation Materials	Glass fiber cotton
System	Circulation fan	Longer sleeves, high temperature and high efficiency motor + centrifugal fan
	Heater	Electric wire wire accelerator
	Control method	PID control + SSR

Why Select MENTEK?

• 1) Top Quality : We have professional QC team for the quality control, we test each function of the test chamber carefully one by one before delivery. All of the products from Mentek are brand new with top quality, we do not provide products with used , refurbish or counterfeits.

• 2) Competitive Prices: Mentek offers you competitive and reasonable market price.

• 3) Excellent Service: We offer complete engineering and technical support, prompt emergency service, remote installation, remote maintenance services and more. We are equipped with over 20 technical and support you anywhere in time .

• 4) Good Material & Workmanship: Besides highly skilled workforce , we use excellent SUS stainless steel, Japan OYO series and Korea TEMI series touch screen controller, international famous brand compressor such as Bizter (Germany),Tecumseh (France) and most of the spare parts are imported with utmost quality as well.

• 5) Highly flexible for customization: The biggest advantage with MTENK climatic chambers is that they are highly flexible for customization. Every test follows a set of procedures as per the defined test standards (ASTM, IEC, MIL, etc.) and sometimes a standard climatic chamber might not be sufficient to conduct a particular test. Our engineers understand this need of the industry well and offer the highest level of customisation like design modification or integration with other applications such as Climatic Chamber with alititude integration, Climatic Chamber with Vibration Integration(AGREE Chamber), etc.
